Fish - FiberLib for VISH 0.3
Fish - The Fiber Bundle API for the Vish Visualization Shell
List of all members
Wizt::Fish< VObject > Struct Reference

This is an antique class which has been replaced by base class VSkale. More...

#include <Fish.hpp>

Inheritance diagram for Wizt::Fish< VObject >:
Wizt::VSkale Wizt::VConnectable Wizt::VSlotContainer< int ExpertLevel > Wizt::VManagedObjectBase Wizt::VConnectionValidatorList Wizt::ValueCacheable MemCore::ReferenceBase< VManagedObjectBase > Wizt::Fish< Fiber::Bundle > Wizt::Fish< Fiber::FragmentCluster > Wizt::Fish< double > FlyingFish Wizt::GridObject Wizt::VertexRenderObject Wizt::Fish< Fiber::Field > Wizt::Fish< Fiber::Grid > Wizt::Fish< Fiber::Skeleton > Wizt::Fish< Fiber::Slice > Wizt::GridAnemone

Additional Inherited Members

- Public Types inherited from Wizt::VSlotContainer< int ExpertLevel >
enum  AttachErrorCode

typedef void AcceptableInputTypes

typedef VSlotSet CreationSlots_t

typedef VSlot::Empty< I > Empty

- Public Types inherited from MemCore::ReferenceBase< VManagedObjectBase >
typedef Object reference_domain_t

typedef WeakPtr< Object, Object > SelfPtr_t

- Public Member Functions inherited from Wizt::VConnectable
virtual void adjustConnections (const RefPtr< VSlot > &ChangedSlot, const RefPtr< VParameter > &par)

VSlotContainer::AttachErrorCode attach (const ParameterID &whichone, VSlotContainer &sourceObject, const ParameterID &sourceName)

AttachErrorCode attach (const RefPtr< VParameter > &OldParam, const RefPtr< VParameter > &NewParam, const string &Member={})

AttachErrorCode attachUniqueObject (const RefPtr< VParameter > &param, const RefPtr< VCreationPreferences > &VCP=NullPtr(), bool ReallyUnique=true)

AttachErrorCode attachUniqueObject (const RefPtr< VSlot > &slot, const RefPtr< VCreationPreferences > &VCP=NullPtr(), bool ReallyUnique=true)

RefPtr< VSlot > Connect (const RefPtr< VParameter > &SourceParam)

RefPtr< VSlot > ConnectInterface (const RefPtr< VSlotContainer > &Provider, const RefPtr< InterfaceBase > &IB)

virtual bool CreatedFilteredConnection (const RefPtr< VParameter > &SourceParam)

- Public Member Functions inherited from Wizt::VSlotContainer< int ExpertLevel >
Ageable & age (const RefPtr< ValuePool > &VP)

const Ageable & age (const RefPtr< ValuePool > &VP) const

const Ageable & ConnectionAge () const

bool ConnectionsHaveChanged (const RefPtr< ValuePool > &VP) const

bool HasYoungerInput (const RefPtr< ValuePool > &Context, int RecursionLevel=0) const

Ageable YoungestInput (const RefPtr< ValuePool > &Context) const

Ageable YoungestOutput (const RefPtr< ValuePool > &Context) const

Ageable YoungestUncachedInput (const RefPtr< ValuePool > &Context) const

bool CheckIfThereExistNewerOutputs (const VRequest &request, bool AdjustObjectAge) const

RefPtr< VSlot > addParameter (const ParameterID &name, int EL, const RefPtr< VParameter > &param, bool overwriteExistingSlot)

virtual bool allowParameterReplacement (const RefPtr< VParameter > &NewParam, const RefPtr< VParameter > &OldParam, const string &localName, int ExpertLevel)

virtual int connectSlots (const VSlotContainerPtr &vobj)

bool removeParameter (const ParameterID &s)

RefPtr< VParameter > getParameter (const ParameterID &s) const

RefPtr< VSlot > getSlot (const ParameterID &s, int &EL) const

bool setSlotValueFromText (const ParameterID &s, const string &ValueText, const RefPtr< ValuePool > &VP, const string &theMember={})

RefPtr< VSlot > findSlot (const RefPtr< VParameter > &param) const

string getSlotName (const RefPtr< VParameter > &param) const

bool AddAction (const ParameterID &s, const RefPtr< ValueActionBase > &VAB)

bool AddAction (const RefPtr< VSlot > &ActionSlot, bool(DerivedObject::*Action)(const RefPtr< VValueBase > &value))

RefPtr< VParameter > mkUniqueParameterInput (const ParameterID &s, const string &ContainerName)

int getExpertLevel (const ParameterID &s) const

int setExpertLevel (const ParameterID &s, int EL)

int getExpertLevel (const RefPtr< VParameter > &) const

int getExpertLevel (const RefPtr< VSlot > &S) const

int setExpertLevel (const RefPtr< VSlot > &S, int EL)

int setExpertLevel (const RefPtr< VParameter > &s, int EL)

bool hasChanged (const ParameterID &s, const RefPtr< ValuePool > &Context) const

bool hasChanged (const RefPtr< VSlot > &, const RefPtr< ValuePool > &Context) const

bool hasChanged (const RefPtr< ValuePool > &Context, int n,...) const

bool hasChanged (RefPtr< ValuePool > Context,...) const

virtual bool ignoreInput (const RefPtr< VSlot > &theSlot) const

bool getParameterValue (Type &Variable, const ParameterID &s, const RefPtr< ValuePool > &VP) const

bool getParameterValue (Type &Variable, const ParameterID &s, const VContext &C) const

bool getParameterValue (Type &Variable, const ParameterID &s, const VRequest &R) const

bool setParameterValue (const Type &Variable, const ParameterID &s, const RefPtr< ValuePool > &VP, bool autoCreateLocalValue) const

bool setParameterValue (const Type &Variable, const ParameterID &s, VContext &C, bool autoCreateLocalValue) const

bool setParameterValue (const Type &Variable, const ParameterID &s, VRequest &R, bool autoCreateLocalValue=false) const

RefPtr< VSlot > addParam (const ParameterID &name, const Type &init, const RefPtr< VCreationPreferences > &VP=NullPtr(), int expertLevel=0, bool overwriteExistingSlot=true)

bool setParameterProperty (const ParameterID &param, const string &Properties, const RefPtr< VValueBase > &Value=NullPtr())

RefPtr< VSlot > addFloatParam (double init, const ParameterID &param, double min, double max, const RefPtr< VCreationPreferences > &IP=NullPtr(), int expertLevel=0)

AttachErrorCode attach (const RefPtr< VParameter > &OldParam, const RefPtr< VParameter > &NewParam, const string &Member={})

int iterateParameters (int expertLevel, VSlotIterator &VIIt) const

int iterateInputSlots (int expertLevel, VSlotIterator &VIIt) const

int iterateInputs (VSlotIterator &VIIt, int expertLevel=0)

int iterate_inputs (const std::function< bool(VSlot &what, int ExpertLevel)>) const

RefPtr< VSlot > getUniqueInputSlot (const type_info &what)

int getNumberOfParameters (int expertLevel) const

virtual bool implements (const type_info &what) const

virtual RefPtr< VParameter > getImplementation (const type_info &what, const string &name={}, const string &member={}) const

RefPtr< VSlot > getImplementationSlot (const type_info &what, const string &Name={}, const string &Member={}) const

VAcceptInfoList_t getAcceptInfoList (const std::type_info &request_type) const

bool provides (const RefPtr< VSlot > &OutputSlot) const

RefPtr< VSlot > findOutputSlot (const RefPtr< VParameter > &Who) const

bool isYounger (const RefPtr< VParameter > &OutputParam, const RefPtr< ValuePool > &VP) const

bool isNewlyConnected (const RefPtr< VParameter > &Who, const RefPtr< ValuePool > &VP) const

bool hasNewlyConnectedOutputs (const RefPtr< ValuePool > &VP) const

void findNewlyConnectedOutputs (const RefPtr< ValuePool > &VP, VSlotSet &WhichOnes) const

RefPtr< VSlot > getOutput (const string &Name) const

RefPtr< MemCore::StringList > getOutputs (const type_info &what=typeid(void)) const

virtual int iterateOutputs (VOutputIterator &VOut, const type_info &just_these=typeid(void)) const

bool registerOutput (const RefPtr< VParameter > &P, const string &AsName={})

bool registerOutput (const RefPtr< VParameter > &P, const string &AsName, const type_info &MemberType, const string &UseMember)

bool registerOutput (const RefPtr< VParameter > &P, const type_info &MemberType, const string &UseMember)

int getNumberOfInputs () const

int getNumberOfOutputs () const

bool hasChangedSlots (const MemCore::Intercube &IC, const RefPtr< ValuePool > &Context) const

auto include_self (const std::tuple< SlotList... > &t) const -> decltype(std::tuple_cat(std::make_tuple(this), t))

 in (VSlotContainer *that, const string &name, int expertLevel=0)

 in (VSlotContainer *that, const string &name, const GridSelector &GS=GridSelector(), int expertLevel=0)

 out (VConnectable *Source, const string &initial_name, const Fiber::GridSelector &InitValue=GridSelector(), const RefPtr< VCreationPreferences > &CP=NullPtr())

- Public Member Functions inherited from MemCore::ReferenceBase< VManagedObjectBase >
auto getObjectCountID () const noexcept

bool isIdentical (const WeakPtr< Object, Object > &PossibleSelf) const noexcept

void mkAutoDestructive ()

refcount_t refcount () const noexcept

 ReferenceBase (Object *that) noexcept

const auto & self () const

refcount_t wrefcount () const noexcept

- Static Public Member Functions inherited from Wizt::VConnectable
static bool attachSlot (const WeakPtr< VSlot > &DestSlot, const RefPtr< VParameter > &ProvidedParam, const string &Member={})

static bool attachSlot (const WeakPtr< VSlot > &DestSlot, const RefPtr< VSlot > &SourceSlot, const string &Member={})

static bool detachSlot (const RefPtr< VSlot > &SourceSlot)

- Static Public Member Functions inherited from Wizt::VSlotContainer< int ExpertLevel >
static const char * AttachErrorCodeMessage (AttachErrorCode)

static bool attachParameter (const RefPtr< VParameter > &theProvidedParam, const WeakPtr< VSlot > &theDestSlot, const string &theMember={})

- Static Public Member Functions inherited from Wizt::ValueCacheable
static ValueCache & consider (MemCore::Intercube &IC, const WeakPtr< VSlot > &VS, const RefPtr< ValuePool > &Context)

static ValueCache & getValueCache (MemCore::Intercube &IC)

static bool hasChangedSlots (const WeakPtrToVSlotContainer &theSlotOwner, const MemCore::Intercube &IC, const RefPtr< ValuePool > &Context)

- Public Attributes inherited from Wizt::VSlotContainer< int ExpertLevel >
 AllLevels

 DestParameterNotFound

 InvalidDestParameter

- Protected Member Functions inherited from Wizt::VSlotContainer< int ExpertLevel >
virtual void setup (const CreationSlots_t &CreationSlots)

- Protected Member Functions inherited from MemCore::ReferenceBase< VManagedObjectBase >
virtual void extremeUnction ()

ReferenceBase & operator= (const ReferenceBase &R)

void suicide ()


Detailed Description

This is an antique class which has been replaced by base class VSkale.

It should go away.

The Fish of a VObject is an abstract base class that holds a (native!) pointer to the Vish object that will be the owner of the various slots. It is only used for the initialization of the slot classes. Therefore all the Fish objects are virtually derived from the Fish object. This ensures that the Fish object is initialized first, and all Fish slots may just use this already initialized pointer from their base class.

The concept is like in the following example. Note that the constructor A(99) is never called here, the argument 99 is completely irrelevant. Using this mechanism, we can give B an argument-free default constructor, and still providing it a well-initialized base class A, since A is constructed in the derived class, not in B.

#include <stdio.h>
struct A
{
A(int i)
{
printf("A: %d\n", i);
}
};
struct B : virtual A
{
B()
: A(99)
{}
};
struct C : B
{
C()
: A(23)
{}
};
main()
{
C cc;
}
